Beskrivelse
Tekniske spesifikasjoner
VOLUME | AXLE | TIRES | HEIGHT DIAMETER | WIDTH* | LENGTH | TARE | MPLW** | Vekt i trekkøye | |
---|---|---|---|---|---|---|---|---|---|
C47 | 4.700 L | 1 axle of 80# 8 studs. Track 1800. Brake 350x60 | 2 tires 550/60-22,5 Flotation | 1.300 mm Ø | 2.100 mm | 3.320 (tank) 5.375 (total) | 2.120Kg | 7.000 Kg | 1.500 kg |
C60 | 6.000 L | 1 axle of 90# 8 studs. Track 1800. Brake 350x60 | 2 tires 550/60-22,5 Flotation | 1.400 mm Ø | 2.100 mm | 4.155 (tank) 5.700 (total) | 2.150kg | 7.500 kg | 1.500 kg |
C70 | 7.000 L | 1 axle of 90# 8 studs. Track 1800. Brake 350x60 | 2 tires 550/60-22,5 Flotation | 1.500 mm Ø | 2.100 mm | 4.250 (tank) 6.150 (total) | 2.500 g | 7.500 kg | 1.500 kg |
C83 | 8.300L | 1 axle of 90# 8 studs. Track 1800. Brake 350x60 | 2 tires 550/60-22,5 Flotation | 1.600 mm Ø | 2.200 mm | 4.470 (tank) 6.205 (total) | 2.750 kg | 7.500 Kg | 1.500 kg |
CT83 | 8.300 L | 2 axles of 90# 8 studs. Track 1800. Brake 350x60 | 4 tires 550/60-22,5 Flotation | 1.600 mm Ø | 2.200 mm | 4.470 (tank) 6.205 (total) | 3.200 kg | 14.000 kg | 2.000 kg |
CT112 | 11.200 L | 2 axles of 90# 8 studs. Track 2000. Brake 350x60 | 4 tires 550/60-22,5 Flotation | 1.700 mm Ø | 2.200 mm | 5.300 (tank) 6.950 (total) | 3.815 kg | 14.000 kg | 2.000 kg |
CT127 | 12.700 L | 2 axles of 90# 8 studs. Track 2000. Brake 350x60 | 4 tires 550/60-22,5 Flotation | 1.800 mm Ø | 2.350 mm | 5.530 (tank) 7.060 (total) | 4.000 kg | 18.000 kg | 2.500 kg |
CT143 | 14.300 L | 2 axles of 10 studs. Track 2000. Brake 400x80 | 4 tires 650/60-26,5 Flotation | 1.900 mm Ø | 2.550 mm | 5.570 (tank) 7.055 (total) | 4.100 kg | 18.000 kg | 2.500 kg |
